Image is for reference only , See Product Specifications

3103-1-00-15-00-00-08-0

Manufacturers:	Mill-Max Manufacturing Corp.
Product Category:	Terminals - PC Pin, Single Post Connectors
Data Sheet:	3103-1-00-15-00-00-08-0
Description:	CONN PC PIN CIRC 0.040DIA GOLD
RoHS status:	RoHS Compliant

Product Description
Customer Reviews

Attribute	Attribute Value
Manufacturer	Mill-Max Manufacturing Corp.
Product Category	Terminals - PC Pin, Single Post Connectors
Series	3103
Packaging	Bulk
Insulation	Non-Insulated
Part Status	Active
Termination	Swage
Mounting Type	Through Hole
Terminal Type	PC Pin
Contact Finish	Gold
Terminal Style	Single End
Board Thickness	0.031" (0.79mm)
Flange Diameter	0.070" (1.77mm)
Contact Material	Brass Alloy
Insulation Color	-
Length - Overall	0.371" (9.42mm)
Length - Above Flange	0.300" (7.62mm)
Length - Below Flange	0.051" (1.30mm)
Material - Insulation	-
Mounting Hole Diameter	0.043" (1.09mm)
Pin Size - Above Flange	0.040" (1.02mm) Dia
Pin Size - Below Flange	-
Contact Finish Thickness	10.0µin (0.25µm)
