0039532294
| Manufacturers: | Molex |
|---|---|
| Product Category: | FFC, FPC (Flat Flexible) Connectors |
| Data Sheet: | 0039532294 |
| Description: | CONN FFC TOP 29POS 1.25MM R/A |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | FFC, FPC (Flat Flexible) Connectors |
| Pitch | 0.049" (1.25mm) |
| Series | 5597 |
| Features | Zero Insertion Force (ZIF) |
| Packaging | Tray |
| Part Status | Active |
| Termination | Solder |
| Housing Color | - |
| Mating Cycles | 30 |
| Mounting Type | Through Hole, Right Angle |
| Actuator Color | - |
| Cable End Type | Straight |
| Contact Finish | Tin Bismuth |
| Flat Flex Type | FFC, FPC |
| Voltage Rating | 200V |
| Locking Feature | Slide Lock |
| Contact Material | Phosphor Bronze |
| Actuator Material | Polybutylene Terephthalate (PBT), Polyester |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.213" (5.40mm) |
| Dielectric Material | Polybutylene Terephthalate (PBT), Polyester |
| Number of Positions | 29 |
| Current Rating (Amps) | 1A |
| Operating Temperature | -20°C ~ 80°C |
| Connector/Contact Type | Contacts, Top |
| Contact Finish Thickness | 39.4µin (1.00µm) |
| Material Flammability Rating | UL94 V-0 |
New and Original electronic components 0039532294 from Huge inventory, fast shipment, Lanka Micro electronics website accept order online、BOM list quotation, and accept various payment term. Right now register as our member,you can get lots of discounts. For any inquiry, welcome to send email to us, or leave a message. ![lanka micro cooperation]()
Lanka Micro Electronic Co.,Limited is a global electronic components distributor. Since company was founded, we always uphold 'best product, best reputation,best service, reasonable price' business philosophy, based on professional quality and consistent professionalism, we win trust and support from the majority of suppliers and customers, and rapidly rising in the fierce market competition.
In Stock 53 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.47 | $1.44 | $1.41 |
Minimum: 1
Request Quote
