OA109EC-UR-1TB
| Manufacturers: | Orion Fans |
|---|---|
| Product Category: | AC Fans |
| Data Sheet: | OA109EC-UR-1TB |
| Description: | FAN EC 120X38MM 90-265VAC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Orion Fans |
| Product Category | AC Fans |
| RPM | 3200 RPM |
| Noise | 43.0 dB(A) |
| Width | 38.00mm |
| Series | OA109EC |
| Weight | 0.64 lb (290.3 g) |
| Air Flow | 106.0 CFM (2.97m³/min) |
| Fan Type | Tubeaxial |
| Features | Dual Voltage, Electronic Commutation (EC), Thermal Overload Protector (TOP) |
| Approvals | CE, cURus, UR |
| Part Status | Active |
| Termination | 2 Terminals |
| Bearing Type | Ball |
| Power (Watts) | 4.90W, 5.20W |
| Voltage Range | 90 ~ 265VAC |
| Static Pressure | 0.340 in H2O (84.7 Pa) |
| Voltage - Rated | 115/230VAC |
| Lifetime @ Temp. | 60000 Hrs @ 40°C |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Size / Dimension | Square - 120mm L x 120mm H |
| Ingress Protection | - |
| Current Rating (Amps) | 0.060A/0.080A |
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) |
