Image is for reference only , details as Specifications
CB1F-R-12V
| Manufacturers: | Panasonic Electric Works |
|---|---|
| Product Category: | Automotive Relays |
| Data Sheet: | CB1F-R-12V |
| Description: | RELAY AUTOMOTIVE SPDT 40A 12V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electric Works |
| Product Category | Automotive Relays |
| Series | CB |
| Features | Resistor, Sealed - Flux Protection |
| Coil Type | Non Latching |
| Packaging | Bulk |
| Coil Power | 1.6W |
| Part Status | Active |
| Coil Current | 134mA |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Operate Time | 15ms |
| Release Time | 15ms |
| Mounting Type | Socketable |
| Coil Resistance | 89.5 Ohms |
| Contact Material | Silver Alloy, Cadmium Free |
| Switching Voltage | 14VDC - Nom |
| Termination Style | Plug In, Quick Connect - 0.250" (6.3mm) |
| Must Operate Voltage | 7 VDC |
| Must Release Voltage | 1.2 VDC |
| Operating Temperature | -40°C ~ 85°C |
| Contact Rating (Current) | 40A |
New and Original electronic components CB1F-R-12V from Huge inventory, fast shipment, Lanka Micro electronics website accept order online、BOM list quotation, and accept various payment term. Right now register as our member,you can get lots of discounts. For any inquiry, welcome to send email to us, or leave a message. ![lanka micro cooperation]()
Lanka Micro Electronic Co.,Limited is a global electronic components distributor. Since company was founded, we always uphold 'best product, best reputation,best service, reasonable price' business philosophy, based on professional quality and consistent professionalism, we win trust and support from the majority of suppliers and customers, and rapidly rising in the fierce market competition.
In Stock 193 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $5.50 | $5.39 | $5.28 |
Minimum: 1
