Image is for reference only , details as Specifications
1913523
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 1913523 |
| Description: | TERM BLOCK PLUG 4POS STR 10.16MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | Green |
| Pitch | 0.400" (10.16mm) |
| Series | COMBICON PC |
| Features | - |
| Packaging | Bulk |
| Screw Size | M4 |
| Part Status | Active |
| Current - UL | 50A |
| Voltage - UL | 600V |
| Current - IEC | 41A |
| Mounting Type | Free Hanging (In-Line) |
| Voltage - IEC | 1kV |
| Torque - Screw | 1.2-1.5 Nm (10.6-13.3 Lb-In) |
| Plug Wire Entry | 180° |
| Contact Material | - |
| Number of Levels | 1 |
| Insulation Height | 1.085" (27.55mm) |
| Termination Style | Screw - Clamping Yoke (Tension Sleeve) |
| Wire Strip Length | 12mm |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | Polyamide (PA), Nylon |
| Number of Positions | 4 |
| Positions Per Level | 4 |
| Contact Mating Finish | Silver |
| Operating Temperature | - |
| Wire Gauge or Range - AWG | 8-20 AWG |
| Wire Gauge or Range - mm² | 0.75-10mm² |
| Material Flammability Rating | UL94 V-0 |
New and Original electronic components 1913523 from Huge inventory, fast shipment, Lanka Micro electronics website accept order online、BOM list quotation, and accept various payment term. Right now register as our member,you can get lots of discounts. For any inquiry, welcome to send email to us, or leave a message. ![lanka micro cooperation]()
Lanka Micro Electronic Co.,Limited is a global electronic components distributor. Since company was founded, we always uphold 'best product, best reputation,best service, reasonable price' business philosophy, based on professional quality and consistent professionalism, we win trust and support from the majority of suppliers and customers, and rapidly rising in the fierce market competition.
In Stock 18 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $17.96 | $17.60 | $17.25 |
Minimum: 1
