Image is for reference only , details as Specifications

52947

Manufacturers:	TE Connectivity AMP Connectors
Product Category:	Terminals - Spade Connectors
Data Sheet:	52947
Description:	CONN SPADE TERM 16-22AWG #4 RED
RoHS status:	RoHS Compliant

Product Description
Customer Reviews

Attribute	Attribute Value
Manufacturer	TE Connectivity AMP Connectors
Product Category	Terminals - Spade Connectors
Color	Red
Series	Plasti-Grip
Features	Serrated Termination
Packaging	Bulk
Insulation	Insulated
Wire Gauge	16-22 AWG
Part Status	Active
Termination	Crimp
Mounting Type	Free Hanging (In-Line)
Stud/Tab Size	4 Stud
Terminal Type	Spring, Snap
Contact Finish	Tin
Contact Material	Copper
Length - Overall	0.811" (20.60mm)
Insulation Diameter	0.105" ~ 0.140" (2.67mm ~ 3.56mm)
Width - Outer Edges	0.203" (5.16mm)
Length - Termination	0.416" (10.57mm)
Material - Insulation	Poly-Vinyl Chloride (PVC)
Tongue Inside Opening	0.203" (5.16mm)
Length - Ring Center to Termination	0.250" (6.35mm)
