The drive uses the full H-bridge driver module power driver chips BTS7960 composed overheating overcurrent protection. Dual BTS7960 H-bridge driver circuit, with a strong drive and braking effect, effectively isolate the microcontroller and motor driver! High current 43A!
Board features:
1, double BTS7960 high current (43A) H-bridge drivers;
2, and MCU 5V isolated, effectively protect the microcontroller;
3, the motor can be achieved is to reverse, two PWM inputs highest 25kHZ frequency;
4, the two streams passing overheating error signal output;
5, isolated chip 5V power (can be shared with the microcontroller 5V);
6, the supply voltage 5.5V to 27V;
